Quick Details

  • Products Status: Stock
  • Type: Desktop
  • Screen Size: No Monitor
  • Processor Brand: Intel
  • Memory Capacity: ≥ 4GB
  • Hard Drive Capacity: 64g ssd
  • Graphics Card Type: Integrated Card
  • Display Type: No monitor
  • Widescreen: Yes
  • Optical Drive Type: NO
  • Processor Main Frequency: Intel Celeron Processor J1800 (Dual-Core 1M Cache,2.41 GHz, up to 2.58
  • Brand Name: Qotom
  • Model Number: Qotom-Q180P
  • Place of Origin: Guangdong, China (Mainland)
  • Color: Black
  • CPU: Intel Celeron Processor J1800 (Dual-Core 1M Cache,2.41 GHz, up to 2.58
  • Memory: Support up to 8GB DDR3
  • Operating System: Support Windows /Linux etc (Can't support windows XP)
  • Power Consumption: 10W
  • Dimension: 135*128*45mm(L*H*W)
  • Weight: 1.5KG

Packaging & Delivery

Packaging Details: Industrial package
Delivery Detail: Shipped in 3 days after payment

Mini computer mainly refers to the small volume which can save space with low power consumption.

Development tendency

1.Power consumption is getting lower and lower,The power consumption idle state is more than 19W of mainstream products recently,The level of energy efficiency grade 1.

2.Performance is getting higher and higher,The cpu appeared 3.0GHz,except large 3D Games,Basically it meet customers requirements and play movies smoothly.

3.Silent running,There are 2 design of mini pc which is with cooling fan and fanless,Almost no noise,The mini pc with fan design,The noise is less than 30 db (A),Daily environment less than 30 db (A),The human ear has been unable to identify.

The advantages of mini computer

Independent small desktop computer,Small volume and save space,Low power consumption,Cost saving and environmental protection,The main application space is the living room     computer,Training,Education,Administrative Office,Government,advertisement and other industries.

Mini pc can meet the below requirements

1.Put it under the television in the living room,It can play Network movie After connecting TV,Searching Internet and viewing photos,It also can download movies (Higher capacity hard disk optional).

2.Business office preferred,Such as E-shop,Online office use,Environmental protection and energy saving,Saves the electricity,The power consumption is more than 17W,Company production of enterprise office,Save a space.

3.Hotel rooms dedicated computer,Elegant appearance,High grade,it’s very convenient in the hotel,Solid state design,Unzerbrechlich, no noise,Low power consumption,Energy-saving power.

4.Dedicated computer education and training industry that’s better performance than a PC,More convenient software compatibility and more colorful,Faster speed,it’s more suitable for students in computer education industry.

5.Industrial computer designed for industrial users reserve and serial port,The design of the machine,Can be fully competent for industrial applications,All solid state design,Completely mute design,Overall plate type design is balancing the needs of the industrial users.

6.Call center users,E-commerce office,Estate agents,All kinds of public window,Cloud services desktop virtualization platform connected to the computer terminal equipment,Task-oriented office workstations.

7.Other special computer:It can also be used as a remote media player,Advertising machine,All-in-one mini pc,POS machine Equipment of the main parts ect,Use of the secondary development into other products.




Configuration of Q180P:
Size:135*128*45mm
Weight:1.5kg
Color:Black
Onboard CPU:Intel Celeron Processor J1800 (Dual-Core 1M Cache,2.41 GHz, up to 2.58)
Memory:Support 1333/1600MHz DDR3 SO-DIMM Memory,1 x Memory Slot Supports up to 8GB Memory
Hard Disk:Support Msata SSD and 2.5" HDD.
Onboard VGA:Intel HD Graphics
LAN:2*RJ45 port Realtek RTL8111E 10/100/1000 Controller
Audio Realtek ALC662 HD Audio
Power Consumption:12W,max 23W
Chipset Intel NM70

Front Panel Connectors
1* Power switch button (Power LED)
1* HDD LED
3* USB2.0 ports
1* USB3.0 ports
1* Microphone port
1* Serial port

Back Panel Connectors
1* DC 12V DC input
1* HD Video port
1* VGA port
2* RJ45 port
1* Speaker port
3* Serial port



Power Supply:DC 12V

Working Temperature:-10℃-55℃

Humidity:0% - 95% Non-Condensing

Packing list:Q180P mini pc,Power adapter,bracket,screw,package box.

Weight:1.5KG /26*23*7cm (with package box)


WIFI and Bluetooth (optional)If you order WIFI, the package box will include 2 pcs antennas.


Please Note: It support Windows 7 / Windows 8 / Windows 10 / Linux OS. We pre-install Unactivated Windows 7 for test and we do not provide any Windows license. If you prefer to other OS, please contact us.
It can act as a host, applying to home, office, library, hospital, restaurant, bank and almost of where need a computer.



Warranty:
1.For all the mini pcs you bought from us, we provide a full one-year warranty.
2.We assure you that all the mini pc and accessories have been tested before delivery.
3.If the products do not work well, contact us, pls! We will try to figure out workable solutions with our professional team.


Mini pc interface
